Specifications
Max Continuous Current | 160 Amps |
Peak Current | 200 Amps |
Operating Voltage Range | 11-26.1 Volts |
BEC Output voltage: | 5.1V to 12.1V adjustable |
Max Continuous BEC Output | 15 Amps @ 8.1 V |
Peak BEC Output | 30 Amps/1s @ 8.1 V |
On Resistance | 0.37mOhms * 2 |
ESC Body Size | 36.5 x 75.0 x 27.0 mm (1.44 x 2.95 x 1.06 in) |
Mounting Tab Dimensions | 24.0 x 84.0mm ( 0.944 x 3.30 in) / M3 Bolt |
Weight (Without Connectors) | 155g ( 5.47oz) |
Drive frequency | 8kHz - 32kHz |
